SR335 alarm unit - Inor
Alarm Unit with Pt100 Input and Double Relay Outputs
SR335 is designed for industrial temperature monitoring with Pt100 sensors in 2- or 3-wire connection.
Two output relays with individually adjustable trip functions are available.
LED’s in the front indicate alarm state and correct power supply.
- Input from Pt100 sensors in 2- or 3-wire connection
- Selectable, pre-calibrated temperature ranges
- Two relay outputs with independent switch functions
- Monostable relays for safe tripping at power failure
- SPDT relays with 6 A switch capacity
- High configuration flexibility with DIP switches
- Trip levels and hysteresis adjustable from the front
- Three front LED’s for trip indication and power supply monitoring
- 4 kV isolation between input, output and power supply
- Protective Separation acc. to EN 50178
- Universal 24 V AC and DC power supply
- DIN-rail mounting
Lees verder
SR360 alarm unit - Inor
Alarm Unit with Current and Voltage Input and Double Relay Outputs
SR360 is designed for monitoring current and voltage signals in the process industry.
Two output relays with individually adjustable trip functions are available.
LED’s in the front indicate alarm state and correct power supply.
- Current and voltage input
- Two relay outputs with independent switch functions
- Monostable relays for safe tripping at power failure
- SPDT relays with 6 A switch capacity
- High configuration flexibility with DIP switches
- Trip levels and hysteresis adjustable from the front
- Three front LED’s for trip indication and power supply monitoring
- 4 kV isolation between input, output and power supply
- Protective Separation acc. to EN 50178
- Universal 24 V AC and DC power supply
- DIN-rail mounting
Lees verder
SR535 alarm unit - Inor
Alarm Unit with Pt100 Input and 4-20 mA Output
SR535 is designed for monitoring Pt100 signals in the process industry.
The unit gives alarm functions for either increasing or decreasing temperatures and for certain error states.
SR535 provides a temperature linear output signal, 4-20 mA, corresponding to the measurement range.
- Direct Pt100 input
- 4-20 mA output
- One temperature monitoring relay
- One error monitoring relay
- Reliable and interference free safety alarm without false alarms
- High configuration flexibility with solder jumpers
- Adjustable time delay, hysteresis and relay functions
- Available for AC or DC power supply
- DIN-rail mounting
- Plug-in screw terminals
Lees verder
SR560 alarm unit - Inor
Dual Channel Alarm Unit for mA/V Signals
SR560 is designed for monitoring mA or V signals in the process industry.
The two channels are fully independent.
The SR560 is specially designed for reliable safety triggering without false alarms.
High configuration flexibility allows for adaptation to required alarm functions.
- Two fully independent isolated channels
- Current and voltage input
- Reliable and interference free safety alarm without false alarms
- High configuration flexibility with solder jumpers
- Adjustable time delay, hysteresis and relay functions
- Available for AC or DC power supply
- DIN-rail mounting
- Plug-in screw terminals
Lees verder
ME544 power supply - Inor
4-channel Power Supply for 2-wire Transmitters
ME544 has four galvanically isolated supply channels for 2-wire transmitters.
The output voltage for each channel is 25 VDC.
Each channel is short-circuit protected and has a current limitation to protect measurement circuits from damage caused by short circuits or other faults.
ME544 cuts the risk for measurement errors caused by earth potential differences with a number of 2-wire transmitters in the same measurement system.
- 4 galvanically isolated supply channels for 2-wire transmitters
- 25 V stabilized supply voltage
- Short-circuit safe
- Current limited to ~35 mA
- Available for AC or DC power supply
- Compact mounting on DIN rail
- Plug-in screw terminals
