X31L – Ascon Tecnologic
The model X31L is an Alarms/events signaling device. The Alarms / events are shown on the 3 digit display and can be detected by10 digital inputs for voltage free contacts or voltage (24 VAC / VDC) whose operation is completely configurable. The instrument can also be equipped with an internal relay and a buzzer that is the sound system for alarms. The model X31SL has the ‘S-touch’ capacitive sensor keyboard system.
Properties
- Digital display 78 x 35 mm, depth 64 mm or 75.5 mm with removable terminal block
- Mechanical or "Sensitive Touch" keyboard
- Degree of protection IP65, with seal
- 1 red or blue display 3 digits, 15.5 mm h
- 10 digital inputs for voltage free contacts orvoltage (24 VAC/VDC)
- Power supply: 24 VAC/VDC, 100... 240 VAC ±10%
- Frequency: 50/60 Hz
- Power consumption: approximately 4 VA
- 1 SPDT relay output (8A-AC1, AC3-3A 250VAC, 1/2 HP 250 VAC, 1/3 HP 125 VAC)
- Internal buzzer
- Connections: Screw terminals 2.5 mm² orremovable connector with screw terminals 2.5mm²
- Overall accuracy: ± 0.5% fs + 1 digit
