Features

• Smallest portable calibration baths - metrology performance
• Conventional compressor based refrigeration system
• Uniformity and stability in mK range
• Calibrate sensors of any dimension
• Fluid ensures perfect heat transfer
• Unique vertical flow design
• Take it anywhere
• All Kambič products are compliant with the F-gas regulation with a GWP of less than 150

Properties

• External dimensions (WxHxD) in mm:
  • OBM: 225 x 638 x 330
  • OBM-LT: 225 x 638 x 330
• Internal dimensions (cross x immersion depth) in mm:
  • OBM: Ø 50 x 210
  • OBM-LT: Ø 50 x 210
• Volume (L): ~1
• Temperature range (°C):
  • OBM: +35 ...+220
  • OBM-LT: -40 ...+130
• Temperature display resolution (°C): 0.001
• Temperature set resolution (°C): 0.01
• Temperature stability (°C):
  • OBM:
  • 0.005 @ +50 °C
  • 0.008 @ +100 °C
  • OBM-LT:
  • 0.007 @ -40 °C
  • 0.005 @ +50 °C
  • 0.008 @ +100 °C
• Temperature uniformity (°C): ± 0.02 @ +50 °C
• Temperature Control: PID
• Power supply: 230V 50/60 Hz (± 10%)
• Interface: RS 232 & USB
• Weight (kg) OBM: ~ 29 OBM-LT: ~35
