Features

• Superior temperature and humidity control
• Perfect for calibration of air temperature and relative humidity sensors
• Convenient front access, side access for cables and probes
• Stable, silent, vibration free climatic conditions
• Superior temperature and Rh uniformity
• Mixed flow humidity control
• Cascade PID control
• Temperature control with FAJT (fluid and air jacket technology) (Ultra-80H)
• All Kambič products are compliant with the F-gas regulation with a GWP of less than 150

Properties

• Temperature range:
  • +10 ... +55 °C (C3-50)
  • -5°... +60°C (K3-90)
  • -60 °C...+80 °C (Ultra-80H)
• Temperature display resolution:
  • 0.001 °C (C3-50, Ultra-80H)
  • 0.1 (K3-90)
• Temperature set resolution:
  • 0.1 °C (C3-50, K3-90)
  • 0.001 (Ultra-80H)
• Temperature stability:
  • STD 0,02 °C (over 30 min, C3-50)
  • see datasheet for K3-90 and Ultra-80H
• Temperature uniformity:
  • 0,5 °C (reference to any point in chamber, C3-50)
  • see datasheet for K3-90 and Ultra-80H
• Relative humidity range: 5 ... 95%
• Relative humidity display resolution: 0.1 °C
• Relative humidity set resolution: 0.1 °C
• Relative humidity stability:
  • ± 0.2 @ 21 °C, 50% Rh (better than ± 0.8 full range) (C3-50, K3-90)
  • ± 0.3 @20 °C, 60% Rh (beter dan ± 0,4 full range) (Ultra-80H)
• Relative humidity uniformity: less than 2% (full range)
• Temperature control: cascade PID, PID (PT-100)
