Features

• Determination of vacuum drying process parameters
• Low temperature evaporation
• Drying curves determination
• Dry mass determination
• Pilot vacuum drying

Properties

• External dimensions (WxHxD) in mm:
  • VS-25 SC: 480 x 602 x 430
  • VS-50 SC: 730 x 510 x 495
  • VS-130 SC: 67 x 856 x 725
• Internal dimensions (WxHxD) in mm:
  • VS-25 SC: 300 x 275 x 307
  • VS-50 SC: 405 x 340 x 370
  • VS-130 SC: 495 x 495 x 530
• Volume (L):
  • VS-25 SC: 25
  • VS-50 SC: 50
  • VS-130 SC: 130
• Temperature range (°C): Tambient ….200 °C
• Temperature display resolution (°C): 0.1
• Temperature set resolution (°C): 0.1
• Temperature stability (°C): 0.1
• Temperature uniformity (°C):
  • VS-25 SC:
  • ± 0.4 °C @ 60 °C
  • ± 0.7 °C @ 100 °C
  • ± 0.8 °C @ 150 °C
  • VS-50 SC:
  • ± 0.7 °C @ 60 °C
  • ± 0.8 °C @ 100 °C
  • ± 1.1 °C @ 150 °C
  • VS-130 SC:
  • ± 0.5 °C @ 60 °C
  • ± 0.6 °C @ 100 °C
  • ± 1.6 °C @ 150 °C
