Features

• Connection options:
  • Lemo connector
  • 5-pin terminal block plug
  • 4-prong plug

Properties

• Operating temperature: -50 ºC..+720 ºC
• Resistance at 0 ºC: 100 Ohm ±0,1 Ohm
• R/t relation: NEN-EN-IEC 60751
• Reproducibility at 0 ºC: ±8 mOhm or ±20 mK (used from -50 ºC to 600 ºC)
• Response time to 63%: typically 32 seconds in stirred water
• Self heating at 1 mA: typically 18 mK in stirred water of 0 ºC
• Stem material: Quartz
• Stem diameter: 6 mm
• Total length: 480 mm
• Immersion depth max: 400 mm
• Immersion depth min: 200 mm
• Immersion effect: 2 mK at 200 mm in oil of 100 ºC, 7 mK at 100 mm in oil of 100ºC.
